- Hydraulics - Pneumatics
- Pump
- Oil pump
- Annovi Reverberi
Oil pump CWX 15.17 Nwith electric motorpistonstationary
Add to favorites
Compare this product
Characteristics
- Fluid
- oil
- Operation
- with electric motor
- Technology
- piston
- Mobility
- stationary
- Domain
- industrial
- Applications
- drain, cleaning, outlet
- Material
- steel, ceramic, bronze, brass
- Protection level
- high-strength
- Other characteristics
- double
- Flow
15 l/min
(3.96258 us gal/min)- Pressure
170 bar
(2,465.642 psi)- Power
5.2 kW
(7.07 hp)- Weight
16 kg
(35.27 lb)
Description
3-piston alternating volumetric pumps for use on cleaning units and industrial systems.Can be coupled to various types of motors, directly or with flexible joint. Pump body and cover in die-cast aluminium alloy. Side cover may be blind or incorporate oil sight glass. Rear cover with oil drain outlet. Pistons driven by crank-connecting rod mechanism. Pump shaft in pressed high-strength steel. Oversized friction bearings. Connecting rods in die-cast special low-friction zinc-aluminium alloy. Bronze connecting rods available. One-piece ceramic pistons. Pump head in nichel-plated brass. Double gasket sealing system. Intake and delivery valves have plugs for easier maintenance.
