Rotary vane vacuum pump VPEHE series
lubricated220VAC110VAC

rotary vane vacuum pump
rotary vane vacuum pump
Add to favorites
Compare this product


Characteristics

Technology
rotary vane
Lubrication
lubricated
Supply voltage
220VAC, 110VAC, 230VAC, 380VAC, 460 VAC, 575 VAC
Number of stages
single-stage
Applications
for heavy-duty applications
Other characteristics
compact, high-flow, large
Ultimate vacuum

0.84 bar, 0.89 bar
(12.18 psi, 12.91 psi)

Flow rate

680 l/min, 1,426 l/min, 2,209 l/min
(179.64 us gal/min, 376.71 us gal/min, 583.56 us gal/min)

Power

1.1 kW, 2.2 kW, 3.7 kW
(1.5 hp, 2.99 hp, 5.03 hp)

Weight

Max.: 335 kg
(738.55 lb)

235 kg
(518.09 lb)

Min.: 106 kg
(233.69 lb)

Description

Self-contained vacuum stations with high-flow vacuum pumps and energy saver circuitry are perfect for custom jigs, special lifters, hold down clamping, and anywhere a large capacity vacuum station is required. ANVER’s VPEHE Vac-Packs are suitable for handling non-porous to porous loads. Designed for use with a wide assortment of lifter assemblies, these high quality Vac-Packs are ruggedly designed for heavy production use. Units are available for heavy duty frames or for stand-alone vacuum stations. Radio Controlled 3 Button Attach / Release / Interlock Transmitter with Plug-In Receiver Hand held device with attach, release and safety interlock push buttons with holster mounted on front handlebar. Plug-in receiver is mounted on side of vacuum generator. Contact Factory for more information. Plug-In Attach / Release / Interlock Control Pendant Attach/Release momentary switch and safety interlock push-button located on control pendant with 10ft long coiled cord. • Load Sensitive Lifting Bail with Safety Lock-Out Switch For generator with GF(Series)T lifting frames, pendant controls are only active when the lifter is lowered completely and there is no load on the lifting shackle. This eliminates the risk of accidental release of a suspended load by the operator. (Feature is not present for generators used on vacuum stations.) • Vacuum Control Module A solid-state Vacuum Control Module combines all the required vacuum generator controls in one rugged unit. This controls all vacuum pump functions, safety lights, and is fitted with a standard audible vacuum leakage warning system.
