Mechanical feeder SF 4 x 130

modularfor presseswindow

AP&T delivers fast and reliable modular transfer automation. We have been delivering to customers since the 1970s, and we are a partner to count on when it comes to automating new or existing mechanical or servo presses, with small to large press bed sizes. We also deliver cost-efficient monobar solutions for both multi-tool setups and C-Frame presses. Standard stroke length X (Pitch): 1000 mm Y (Clamp): 2 x 400 mm Z (Lift): 200 mm Max. stroke length X (Pitch): 2000 mm in increments of 100 mm Y (Clamp): 800 mm in increments of 100 mm Z (Lift): 1000 mm in increments of 200 mm Max. distance master–repeater: 12000 mm Max. transfer rail length: 8500 mm Max. handled weight: 500 kg
