PCIe SSD PH150-μSSD

externalM.2industrial

Apacer PCIe BGA SSD PH150-μSSD (M.2 1620) presents a revolutionary breakthrough of NAND flash storage technology. This micro sized SSD delivers all the technological benefits in NAND based storage solution with ultra speed PCIe Gen3 x4 interface in an embedded BGA form factor, compatible with JEDEC PCIe M.2 1620. Formed in a size of an IC chip, the performance level can reach up to 2,260 MB/s for read and 1,530 MB/s for write. Regarding reliability, PH150-μSSD is built with a powerful PCIe controller that supports on-the-module ECC as well as efficient wear leveling scheme, and implemented with LDPC (Low Density Parity Check) ECC engine to extend SSD endurance and increase data reliability. With Apacer’s SLC-liteX technology, PH150-μSSD performs with higher number of P/E cycles up to 30,000 times. Furthermore, PH150-μSSD is equipped with a built-in thermal sensor to monitor the temperature of the SSD via S.M.A.R.T commands and configured with thermal throttling to dynamically adjust frequency scaling to enhance data reliability and provide sustained performance while overheating. For highly-intensive applications, End-to-End Data Protection ensures that data integrity can be assured at multiple points in the path to enable reliable delivery of data transfers. Security-wise, Advanced Encryption Standard (AES) and Write Protect ensure data security and provide users with peace of mind knowing their data is safeguarded against unauthorized use at all times. PH150-μSSD also adopts the latest page mapping file translation layer and comes with various implementations including flash block management
