Planetary gearbox AHK seriescoaxial200 - 500 Nm100 - 200 Nm
Add to favorites
Compare this product
Characteristics
- Type
- planetary
- Shaft orientation
- coaxial
- Torque
- 200 - 500 Nm, 100 - 200 Nm, 20 - 50 Nm, 50 - 100 Nm, 500 - 1000 Nm, > 10 kNm, 1 - 2 kNm, 2 - 5 kNm, 5 - 10 kNm
- Number of stages
- two-stage, four-stage
- Performance
- high-efficiency, low-noise, high-precision
- Rotational speed
Max.: 6,000 rpm
(37,699.11 rad.min-1)Min.: 1,600 rpm
(10,053.1 rad.min-1)- Backlash
0.03 °
- Gear ratio
Max.: 10,000 unit
Min.: 12 unit
Description
OVERVIEW
Output torque
T2N : 24 Nm - 5615 Nm (2 St)
T2N : 1225 Nm - 10980 Nm (4 St) Ratios:
2-stage : 12 / 15 / 16 / 20 / 25 / 28 / 35 / 40 / 49 / 50 / 70 / 100
4-stage : 1225 / 1400 / 1750 / 2000 / 2800 / 3500 / 5000 / 7000 / 10000
Low backlash
2-stage : ≤2arcmin (AHK064≤3)
4-stage : ≤2arcmin
High efficiency
2-stage : ≧ 94%
4-stage : ≧ 90%
Easy mount
Low noise
