Type 2 surge arrester ATSUB-R 65-300

for power suppliessingle-poleDIN rail

Protector for power supply lines. Connection for remote warning. Single-pole. Type 1+2. Uc = 320 VAC. Iimp = 15 kA. Imax =65 kA. Up(In) = 1800 V. Up(1,2/50) = 1100 V. Size 1DIN. Tested and certified as a protector Type 1+2 according to the standard EN IEC 61643-11. Suitable for Categories II, III, IV according to ITC-BT-23. Single-pole protection. Containing zinc oxide varistors able to withstand very high currents. Coordinable with protectors of series ATSHOCK, ATSHIELD and ATCOVER. Short response time. Does not produce deflagration. Their activation causes no interruption in power supply. Thermodynamic control device. Voltage-free contact for the remote control. ATSUB series protectors have been tested in official and independent laboratories, obtaining their characteristics according to relevant standards.
