DC servo motor V0250-214-B-000
brushless48 VNEMA 23

DC servo motor - V0250-214-B-000 - Applied Motion Products - brushless / 48 V / NEMA 23
DC servo motor - V0250-214-B-000 - Applied Motion Products - brushless / 48 V / NEMA 23
Add to favorites
Compare this product


Characteristics

AC/DC
DC
Type
brushless
Voltage
48 V
Configuration
NEMA 23
Applications
with built-in encoder
Other characteristics
high-resolution
Power

200 W
(0.272 hp)

Intensity

Min.: 5.8 A

Max.: 17 A

Torque

Min.: 0.56 Nm
(0.413 ft.lb)

Max.: 1.6 Nm
(1.1801 ft.lb)

Rotational speed

Min.: 3,350 rpm
(21,048.67 rad.min-1)

Max.: 4,000 rpm
(25,132.74 rad.min-1)

Operating temperature

Min.: 0 °C
(32 °F)

Max.: 40 °C
(104 °F)

Description

* Brushless DC servo motor * Standard NEMA frame size * Bearing-mount encoder * High resolution, incremental encoder (2048 lines, 8192 counts) Brushless DC servo motor with high resolution encoder feedback. Part Number: V0250-214-B-000 Frame Size: NEMA 23 Continuous Torque: 5.0 in-lb Peak Torque: 15 in-lb Rated Voltage: 48 VDC Rated Power: 200 watts Rated Speed: 3350 rpm Peak Speed: 4000 rpm Rated Current: 5.8 A rms Peak Current: 17.0 A rms Torque Constant: 0.885 in-lb/A Voltage Constant: 10.7 V/krpm Armature Resistance: 0.89 ohms Armature Inductance: 4.2 mH Motor Length: 4.09 inch Rotor Inertia: 3.82E-03 oz-in-sec2 Weight: 3.7 lbs Integral Holding Brake: No Storage Temperature: -10 to 85 °C Operating Temperature: 0 to 40 °C Insulation Class: Class B (130 ºC) Shaft Diameter: 6.35 mm (0.250 inch) Maximum Radial Load: 13 lbs Maximum Thrust Load: 6.6 lbs
