Salmon gutting line PRSG-SG

semi-automatic

The ProSign Dual Gutting Line for salmon and several other fish types. The machine can be used for further purposes, such as extracting spawn for caviar production. The semi-automatic gutting provides a quick and clean station for the gutting of the fish. The waste is disposed of via Vacuum Spoons and Pump, leaving the area clean and ensuring an ergonomic working station. Capacity, accuracy and performance in grading and batching is subject to the type and condition of the raw material and the condition and settings of the machine, as well as the operating environment. It also depends on the way the material is fed into the machine. Process & Flow * Slotted infeed conveyor with loading station. After de‐icing the slotted conveyor transports the fish from the in‐feed table on to the in‐line conveyor. The operators drag the fish over to the conveyor and put them in to the slots with the head facing the product direction. The speed of the whole system is based on the speed of these two operators. * Inline infeed speed up conveyor This straight conveyor accelerates the fish after the drop from the conveyor slot, to create adequate space between each fish to allow for accurate individual weighing when passingover the dynamic weighing unit. * Dynamic Weighing Unit (with batching) Dynamic weighing unit that weights the fish and selects the correct bin or gate for it according to its weight, then it sends it to the discharge unit. The dynamic scale has at its best and with the correct in‐ feeding a capacity of 45 - 50 pieces /minute.
