Black Powder Coated or Stainless-Steel Bezel
5-Wire Resistive Touch or Tempered Glass
Up to 8GB DDR3 / 16GB DDR3 / 32GB DDR4
Dual Gigabit LAN
Removable 2.5" SATA SSD
1 x PCIe x16
LCD Display
Backlight Lifetime (Hours) - 50,000
Visual Characteristics
Colors - 16.7 million
Aspect ratio - 4:3
Viewing angle (V/H) - 140° / 160°
Contrast ratio - 700 : 1
Brightness - 300 nits
Touch Screen
Technology - 5 Wire Resistive
Interface - USB
Driver - XP, Win7, Win10
Front Bezel
NEMA 4 - Black Powder Coated
NEMA 4x - Stainless Steel (Optional)
Rack Mount Bezel - N/A
System
CPU - Intel i7-3612QM
Chipset - Intel QM77
Memory - Up to 16GB DDR3
Video Controller - Intel HD Graphics 4000
External Video Output - DVI / HDMI / Display Port
Storage Option - 1 x 2.5" SATA SSD
CFast - N/A
Keyboard / Mouse - 1 x PS / 2 connector
Audio - Line in, Line Out, Mic-In
Watchdog Timer - Programmable 1 - 255 sec
Remote Boot - PXE, ThinManager Ready
Expansion Slot - 1 x PCIe x16
I/O Communication
USB Port - 4 x USB 2.0, 2 x USB 3.0
Serial Port - 2 x RS-232/422/485
IEEE 1394 - N/A
LAN - Dual Gigabit LAN
Parallel - N/A
GPIO - N/A
Smart Battery
External Smart Battery - N/A
OS Support
OS Support - WinXP Pro, Win7, Win10
