Projected Capacitive Touch Screen
Aluminum or Stainless-Steel Flush Bezel
Intel Celeron J1900 @ 1.99GHz / Atom E3845 @ 1.91GHz CPU; Intel i7-6600U, i5-6300U, Celeron-3855U
Up to 8GB DDR3/ Up to 16GB DDR4 SO-DIMM
Optional 2.5" SSD
Dual Gigabit Ethernet
4 x RS-232/422/485 BIOS Selectable
1 x 8-bit GPIO (4-bit Input, 4-bit Output)
1 x USB 3.0, 3 x USB 2.0 ports
Backlight Lifetime - 50,000 hours - 50,000 hours
Visual Characteristics -
Colors - 16.7 million - 16.7 million
Aspect Ratio - 16:9 - 16:9
Viewing Angle (V/H) - 140° / 160° - 140° / 160°
Contrast Ratio - 700 : 1 - 700 : 1
Brightness - 400 nits (Typical) - 400 nits (Typical)
Touchscreen -
Technology - Projected Capacitive - Projected Capacitive
Interface - USB - USB
Driver - Windows 7, 8 & 10 - Windows 10
Front Bezel -
NEMA 4 - Aluminum - Aluminum
NEMA 4x - Stainless Steel (Optional) - Stainless Steel (Optional)
System -
CPU - Intel Celeron J1900 @ 1.99GHz / Atom E3845 @ 1.91GHz CPU - Intel i7-6600U, i5-6300U, Celeron-3855U
Chipset - Bay Trail - Skylake
Memory - Up to 8GB DDR3 SO-DIMM - Up to 16GB DDR4 SO-DIMM
Video Controller - Intel Gen7 Intel Graphics DX 11, OGL3.2 - Intel HD Graphics 520
External Video Output - VGA - VGA
Storage Option - 2.5" SSD - 2.5" SSD
CFast Card - Optional - Optional
Keyboard / Mouse - USB / PS2 - USB / PS2
Audio - N/A - N/A
Watchdog Timer - Programmable 1 - 255 sec - Programmable 1 - 255 sec
Remote Boot - ThinManager Ready, PXE - PXE
Expansion Slot - Mini PCIe x 2 - Mini PCIe x 1
I/O Communication -
USB Port - 1 x USB 3.0, 3 x USB 2.0 - 1 x USB 3.0, 3 x USB 2.0
Serial Port - 4 x RS-232/422/485 BIOS Selectable - 4 x RS-232/422/485 BIOS Selectable
