SoC system-on-chip DMA-230

The Direct Memory Access (DMA) controller enables the movement of blocks of data from peripheral to memory, memory to peripheral, or memory to memory without burdening the processor. The DMA-230 is a low gate count (3-10k gates) micro-DMA engine targeting Cortex-M3 systems and other low-power and cost-sensitive applications. The device offers excellent performance at low gate count and all the code is stored in system RAM rather than in registers. Using this component enables Cortex-M1 and Cortex-M3 based systems to remain low cost through reduced gate count and enabling scaling down the frequency of the processor in the system for reducing overall power consumption. Features and Benefits Improve System Performance Efficient use of DMA can significantly improve system performance in multiple dimensions. For example, using a DMA controller can offload a processor and either reduce power consumption, or boost the processor performance, or a combination of both. Support High-End and Energy Efficient Systems AMBA DMA controllers provide a centralized DMA processing capability that is high performance and highly flexible, and at the same time, is area efficient. Designed for Critical Tasks The DMA controller is a low-power, high-performance IP core that performs critical tasks within the AMBA system and is designed for optimal compatibility with Arm Cortex, Mali multimedia, and CoreLink System IP, and as a natural complement to interconnect and memory controllers.
