Diaphragm valve GP-2000pneumaticpressure-reducingfor steam
Add to favorites
Compare this product
Characteristics
- Type
- diaphragm
- Operation
- pneumatic
- Function
- pressure-reducing
- Media
- for steam
- Body
- iron
- Applications
- process, heating
- Associated function
- reducing
- Other characteristics
- high-performance
- DN
Max.: 150 mm
(5.906 in)Min.: 15 mm
(0.591 in)- Pressure
20 bar
(290.1 psi)- Temperature
220 °C
(428 °F)
Description
The GP-2000 is a high-performance, externally piloted reducing valve for steam service with large-capacity requirements. Typical use is on intermittent service, including applications such as heat exchangers, steam coils, rotating dryers, process equipment and heating systems. With a 20:1 rangeability and high Cv, the GP-2000 is reliable and accurate (+/-1% of pressure set point from 5% to 100% of flow) over a long, trouble-free service life. Hardened stainless steel working parts are renewable in-line. The GP-2000 is single-seated for dead-end service, and it is available with both NPT (1/2″–2″) (15–50 mm) and flanged connections in 2″–6″ sizes (50–150 mm).
