IP20 limit switch GS225
plastic housingadjustablefor electrical applications

IP20 limit switch
IP20 limit switch
Add to favorites
Compare this product


Characteristics

Protection level
IP20
Other characteristics
plastic housing, adjustable
Domain
for electrical applications, monitoring

Description

• Limit switch for monitoring unit signals • Two adjustable limit values ​​(floating) • Switching function min. or max. • Potentiometer with scale 0…100% • Hysteresis and time delay is adjustable • Inputs 0/0, 2…1 V, 0/2…10 V, 0/4…20 mA • Supply voltage 18…30 Vdc unregulated • Supply voltage 230 Vac/115 Vac or 24 Vac or 24 Vdc • Plastic housing for mounting on a 35 mm standard mounting DIN-rail according to EN 50022 Serves for controlling measuring values which are represented as electrical currents. A potential-free contact is switched when the corresponding presetted nomial value eith is fallen short (min.-function) or is exceded (max. function). Hysteresis and time delay are adjustable inside the unit by trimmers. TECHNICAL SPECIFICATIONS: Entrance: 0 / 0.2 … 1V, 0/2 … 10V, 0/4 … 20mA Supply voltage: Approx. 18 … 23 Vdc, unstabilized Setpoint setting: Poti with scale 0 … 100% Hysteresis: Adjustable in the device from 0.25 … 5% Time Delay: Adjustable in the device from 0 … 7 s Switching function: Min. Or max. (Adjustable in the device) Contact output: potential-free NO contact max. 250 Vac, 8 A Resolution of the scales: Approx. 5% ACCURACY / ERROR LIMIT: Temperature drift: ± 0,2 % / 10 K
