Proportional valve AVENTICS™ Series 615 Sentronic TWIN

plugpneumaticservo-driven

The AVENTICS Series 615 Servotronic Digital is a highly dynamic 3-way proportional valve with digital control that is designed for applications with constant air or neutral gas flow. The combination of innovative pneumatic technology, high-precision mechanics, and modern electronics allows for quick control of pressure in relation to a signal received from the controlling electronics. The valve is provided with a precision-lapped steel spool and sleeve with a hardened and tempered surface enabling very high pulse frequencies and extremely short response times. Control loop parameters are easily configured and optimized for specific customer requirements using AVENTICS Data Acquisition Software (DaS) and a PC connection. Specifications Function3 way - 3/2 Normally Closed Valve ActuationProportional Body MaterialAluminum Voltage24 VDC Frequency50/60 Hz MediaAir, Inert Gases, Natural Gas, Oxygen Operation EnvironmentIndoor Port TypeG ISO228/1-G BSPP, NPTF Standard & RegulationsCE, EAC, IP65 Features Compact monobloc construction with integrated electronics and sensor High reliability and long service life due to precision mechanics combined with simple control technology Valve components designed to provide control at an extremely low hysteresis Intelligent digital communication enables simple operation DaS software allows selection of personalized settings to optimize control loop performance
