Digital timer TT73multi-functionprogrammable
Add to favorites
Compare this product
Characteristics
- Technology
- digital
- Function
- multi-function
- Other characteristics
- programmable
- Voltage
Max.: 240 V
Min.: 12 V
Description
Digital timer, 2 outputs
Digital microprocessor timer with 2 outputs, which offers the possibility to program:
-up to 3 set points
-5 operating modes for OUT1
-4 operating modes for OUT2
-4 time scales
-4 counting enabling functioning modes and 2 counting modes (UP or DOWN)
It can also be equipped with an internal battery that allows the counting to continue even in the absence of power supply.
FUNCTION -
Timer
DIMENSIONS -
72 x 72 mm
DISPLAY -
1 display with 4 digit
POWER SUPPLY -
12 Vac/Vdc, 24 Vac/Vdc, 100… 240 Vac
INPUTS -
2x voltage and free voltage contacts
NUMBER OF OUTPUTS -
2
OUTPUTS -
Relay or voltage
SPECIAL FUNCTIONS -
Multi-scale, multifunction
CERTIFICATIONS -
CE
Catalogs
CATALOGO PRODOTTI 2014/2015
113 Pages
