Roller conveyor RBI190 series

inclinedtransport

RBI 190 Roller Bed Incline Description: The Model RBI190 incline conveyor allows movement of cartons, boxes, etc., floor-to-floor in either direction. The roller bed provides a higher capacity and can also be used to increase elevation in gravity flow situations. Construction: Belting: PVC 120 rough top. Bed: 1.9" x 16 ga. galvanized steel rollers on 6" centers. Drive Pulley: 8" diameter crowned and lagged with 1-7/16" diameter shaft. Frame: 3-1/2" x 1-3/8" x 11 ga. steel channel. Tail Pulley: 4" diameter crowned with 1-3/16" diameter shaft. Return Rollers: 1.9" diameter adjustable. Take-Up: 12" take-up travel. Bearings: Sealed and prelubricated with cast iron housings. Motor: 3/4 HP 230/460 3 phase 60 HZ TEFC, other voltages & HP available. Drive: Right hand center drive. Power Feeder: Not included, chain driven power feeder available to provide a smooth transition to incline. Noseover: Double noseover included, adjustable from 0-30 degrees. Belt Speed: 60 FPM constant, variable and other constant speeds available. Controls: Not included, available are manual starters, magnetic starters, push button stations, photo eyes, etc. Floor Supports: Not included, refer to Supports section, castered supports available. Support BF is same as conveyor BF (Between Frame) or belt width plus 3".
