Tape position sensor positape® WB12
magneticCANopenSSI

Tape position sensor - positape® WB12 - ASM Automation Sensorik Messtechnik GmbH - magnetic / CANopen / SSI
Tape position sensor - positape® WB12 - ASM Automation Sensorik Messtechnik GmbH - magnetic / CANopen / SSI
Add to favorites
Compare this product

Go to the ASM Automation Sensorik Messtechnik GmbH website for more information

Characteristics

Type
tape
Technology
magnetic
Output signal
CANopen, SSI
Measurement object
metal
Protection class
IP67, IP69
Applications
heavy-duty
Other characteristics
absolute
Measuring range

4,000 mm
(157.48 in)

Linearity

0.1 %

Ambient temperature

Min.: -40 °C
(-40 °F)

Max.: 85 °C
(185 °F)

Description

Output - Voltage 0.5... 10 V Voltage 0.5... 4.5 V Current 4 ... 20 mA, 3-wire technology Voltage or current output, programmable Voltage or current output, redundant Resolution - < 0.05 mm Linearity - Up to ±0.05 % f.s. Sensing device - Magnetic absolute encoder Housing material - Aluminum Measuring tape: stainless steel, 10 mm wide, 0.08 mm thick Connection - Connector M12 Weight - approx. 3 kg
