Pico-ITX motherboard SOM-P102D

Intel® Apollo LakeIntel® Pentium® N4200DDR3L SO-DIMM

Processor System N4200, QC, 1.1 GHz, 6 W Chipset - SoC BIOS - AMI SPI 128 Mbit Form Factor Dimensions - PICO-ITX (3.9-in x 2.8-in, 9.0 cm x 7.1 cm) Memory Technology - Dual Channel DDR3L 1866 MHz Capacity - 8 GB Socket - 1 x 204-pin SO-DIMM Graphics Controller - Intel® Gen9 Graphics DX 12 HDMI - HDMI 1.4b Max resolution up to 4096 x 2160@24Hz LVDS - Dual channel 24 bit up to 1920x1200@60Hz MultiDisplay - Dual Display Expansion Slot M.2 - 1 x Key E (2230)with PCIe x1 and shared USB 2.0 for Wireless Audio Interface - Realtek ALC887, High Definition Audio. Line-out,Mic-in Ethernet Controller/ Speed - 1 x Intel® I210AT with 10/ 100/1000 Mbps Connector - 1 x RJ-45 Rear I/O HDMI - 1 x HDMI 1.4b Ethernet - 1 x 1 Gigabit LAN USB - 1 x USB 3.1 Gen1 Internal Connector USB - 1 x USB 2.0 (2 x 2.54 pitch header) COM - 1 x COM1 (RS-232/422/485) 1 x COM2 (RS232) GPIO - 4 x GPI + 4 x GPO LVDS - 1 SATA PWR Output - 1 Speaker Header - 1 Storage mSATA - 1 x Full size with SATA3 and USB 2.0 SATA - 1 x SATA3 (6Gb/s) Watchdog Timer Output - From Super I/O to drag RESETCON# Interval - 256 Segments, 0, 1, 2, ...255sec Power Requirements Input PWR - 12V DC-In Power On - AT/ATX supported -AT: Direct PWR on as power input ready -ATX:Press button to PWR on after power input ready Environment Operating Temp - 0ºC ~ 60ºC Storage Temp - -40° C – 85° C Operating Humidity - 5% ~ 90% Storage Humidity - 5% ~ 90% Accessories Gift Package - 1 x SCREW M2,D=5.3 (13G020302010AK) 2 x SCREW FOR WIFI CARD (13G020305011AK) 1 x CPU SINK 100*72mm (13G070362000AK) 1 x USB 2.0 Cable (14G000500060AK) 1 x COM Cable (14G000000340AK) Bulk Package - 2 x SCREW M2,D=5.3 (13G020302010AK) 2 x SCREW FOR WIFI CARD (13G020305011AK)
