Needle valve IB seriesmanualfor controlshut-off
Add to favorites
Compare this product
Characteristics
- Type
- needle
- Operation
- manual
- Function
- for control, shut-off
- Media
- for water, for air, for compressed air
- Body
- threaded, soft-seat, weld, stainless steel, alloy, titanium
- Applications
- for industrial applications
- Number of channels
- 3-way, 4-way, 2-way, 6-way and higher, 5-way
- DN
Min.: 3 mm
(0.118 in)Max.: 22 mm
(0.866 in)- Pressure
Max.: 207 bar
(3,002.3 psi)- Temperature
Min.: -53 °C
(-63 °F)Max.: 148 °C
(298 °F)
Description
Athena Instrument Ball Valve
Performance
-Compact design, with strong flow capability
-V-type packing: better seal, ware-resistance,lower torque force
-Variety of end connection type available
Features
-Working Pressure: up to 3000 psi(207bar)
-Working Temperature -65℉ to 300℉ （-53℃ to 148℃）
-Material: 316ss, titanium, other material as request
-Valve Seat: PTFE, RPTFE, UHMWPE
-Flow Way: straight and 3-way, 4-way, 5-way, 6-way, 7-way available
-End Connection Type: metric and fractional tube fittings,
-NPT threads, ISO/BSP threads, weld ends
-End Connection Size: 1/16 to 3/4 in., 3 to 22 mm
