Rubber-tired dumper D450AHG

dieselswivel-skiparticulated-chassis

Versatile, cost-effective and flexible. The D450AHG, with its 4.5-ton (9,900 lbs) payload and 180-degree swing skip, is the dumper with the best payload to price ratio available on the market. The D450AHG is an all-terrain vehicle which, thanks to the design of its skip, is capable of quickly and easily transporting up to 2,670 litres (4.5 cu ya). Specially designed for major work on every type of terrain, it can meet the most demanding payload requirements, despite its small size. With its hydrostatic transmission, maximum comfort and safety are assured. Thanks to the transmission brake, it prevents the machine from moving under its own weight on slopes, without you even touching the brake pedal. Also, as there is no need to change gears, the driver can focus on the movements of the machine and its load. Technical data General Unloading system - Rotating Chassis - Articulated Water hopper capacity - 1370 l Level hopper capacity - 2055 l Heaped hopper capacity - 2670 l Transmission - Hydrostatic Engine Brand - Kubota Model - V2403M - E3B Power - 36.5 kW Torque - 160@1600 No. of cylinders - 4 Emissions - Stage IIIA - EPA Tier 4i Noise level - 101 dB(A) Driving Max. speed - 19 Km/h Maximum gradient - 35 % External turning radius - 4830 mm Traction - 4x4 Tyres - 12,0/75-18 Hydraulic system Main pump - 12 cc gear pumps Hydraulic circuit - 31.2 l/min Working pressure - 170 bar Deposit capacity Fuel - 44 l Hydraulic system - 40 l Brakes Service - Hydraulic, sealed, multi-disc Parking - Mechanical, sealed, multi-disc
