Power factor panel meter MX4W Series

digitalLCD displaycompact

The MX4W series digital panel meters feature LCD displays with large, easy-to read white PV characters (display height: 19 mm). The DIN W 96 x H 48 mm panel meters also feature 12-segment displays, useful for displaying various alphanumeric characters. The series also features diverse input options for application in various settings. The input and power terminals are isolated which allow multiple units to be powered by the same power supply. The panel meters also feature various other options including power factor display function for displaying analog outputs from power factor converters. The compact 20 mm rear-length size allows flexible installation in limited spaces. Main features LCD display with easy-to-read white PV characters Isolated input and power modules allow powering of multiple units using a single power supply Compact, space-saving design (rear-length: 20 mm) : reduced rear-length size by 80% compared to same DIN size panel meters (MT4W) Various input options (by model) - Input options: DC/AC voltage, DC/AC current Maximum allowed input: 500 VDC, 500 VAC, DC 5 A, AC 5 A Display range: -9999 to 9999 High/low-limit display scale function AC frequency measurement (range: 0.100 to 1200 Hz) Preset output: OUT1, OUT2 (NPN/PNP open collector output) Power factor display/output function : displays analog outputs (1-5 V, 4-20 mA) from power factor converters as -0.50~1.00~0.50 Various functions : peak display value monitoring, display cycle delay, zero-point adjustment, peak display value correction, etc. Power supply: 24-240 VAC 50/60 Hz, 24-240 VDC universal
