3.5" single-board computer ECM-TWL

Intel® Core™ 3 Processor N355Intel® Processor N150Intel® Processor N250

Bottom Layer Soldered Processor DC in +9V ~ +36V System Information I/O Chipset EC iTE IT5782VG Watchdog Timer H/W Reset, 1sec. ~ 65535sec and 1sec. or 1min./step BIOS AMI BIOS, 256Mbit SPI Flash ROM H/W Status Monitor CPU temperature monitoring Voltages monitoring CPU fan speed control TPM Onboard NuvoTon_NPCT760AABYX supports TPM 2.0 Display Graphic Chipset Intel® UHD Graphics Multiple Display Triple Display Audio Audio Codec Realtek ALC888S HD Audio Decoding Controller Audio Interface Line-in, Mic-in, Line-out Power Requirement Power Mode AT/ATX (Default Setting: AT) Certification Certification Information CE, FCC Class, RoHS Compliant I/O DIO 1 x 8-bit GPIO Mechanical & Environmental Operating Temp. 0°C ~ 60°C (-4~140°F) with 0.5m/s Air Flow Storage Temp. -40°C ~ 85°C (-40°F ~ 185°F) Operating Humidity 40°C @ 95% Relative Humidity, Non-condensing Weight 0.44lbs (0.2kg) Power Requirement DC in +9V ~ +36V Dimension (L x W) 5.7" x 4" (146mm x 101mm)
