Electrical power supply connector SMP series

PCBinsulationDC

Apply to RF signal transmission between RRU and antenna, RRU and AAU. Small size, light weight； High density installation； Three kinds of interfaces: full detent, limit detent and smooth bore; Wide frequency range, good electrical performance； Good vibration resistance performance； Apply in PCB connection or some conditions having weight requirements, and small working space. Frequency range - DC～12.4GHz（recommended） 12.4～26.5GHz（recommended） 25.6～40GHz（operating range） Insulation resistance - 1000M Contact resistance - center conductor: ≤6mΩ , outer conductor: ≤8mΩ (stainless steel housing) VSWR - DC～12GHz，≤1.15 12～26.5GHz，≤1.35 26.5～40GHz，≤1.6 Inserting loss - ≤0.05√F(GHz)dB Endurance (cycle) - full detent, 100 cycles limit detent, 500 cycles smooth bore, 1000 cycles
