Pneumatic spray unit
automaticoscillatingpiston

Pneumatic spray unit - Bakon B.V., food equipment - automatic / oscillating / piston
Pneumatic spray unit - Bakon B.V., food equipment - automatic / oscillating / piston
Add to favorites
Compare this product


Characteristics

Technology
pneumatic
Other characteristics
automatic, oscillating, piston
Flow rate

2 l/min
(0.5 us gal/min)

Description

The AUTOMATIC ROTATING GLAZE SPRAYING machine is a rotating and high-volume glaze spray machine with the same functionalities as the AUTOMATIC GLAZE SPRAYING machine. A rotating spray bridge ensures high volumes of products which leave the machine as if they were sprayed piece by piece. Overspray of glaze or marmelade is reduced to a minimum and is collected for re-use. The AUTOMATIC ROTATING GLAZE SPRAYING machine not only delivers beautiful products but allows you to work economical and competitive as well. Key features Various working widths from 400 to 1200 mm. Movable stainless steel frame with 2 rigid and 2 swivel wheels with brakes. Conveyor with full bed polycords (∅ 6 mm) and scraper. Frequency converter to control the speed of the conveyor. In height adjustable rotating spray bridge with various number of spray guns. Pneumatic piston pump with ceramic coated shaft. Double glaze filter to prevent nozzle problems. Stainless steel back pressure valve guarantees a uniform spray view. Heating capacity from 20 to 85 °C and glaze output of 2 ltr / min. Overspray can be re-used from the funnel under the conveyor. Operation Heated glaze is pumped up from the funnel with an air-operated piston pump and transferred through an electrical heated spiral heater and a stainless steel filter to the rotating spray bridge. The glaze returns from the spray bridge to the pump cabinet through a hose and a back pressure valve to keep an even pressure in the system. The spray bridge is adjustable in height and is fitted out with a various number of spray guns. The conveyor that transports the products has a per product adjustable speed.

VIDEO
