Blade cutting machine CUT535PAfor plasticstubefor the automotive industry
Add to favorites
Compare this product
Characteristics
- Technology
- blade
- Material
- for plastics
- Product handled
- tube
- Applications
- for the automotive industry
- Other characteristics
- automatic
- Operating pressure
8 bar
(116.03 psi)- Overall length
1,190 mm
(47 in)- Overall width
645 mm
(25 in)- Height
1,472 mm
(58 in)- Weight
160 kg
(352.74 lb)
Description
• Capacity on 4 Spirals Hoses : 2" R15 Ø80mm
• Automatic cutting capacity : ¼” a ¾” R2
• Blade : : 350mm
• Standard Voltage : 400V | 50Hz | 60 Hz
• Motor Power Kw : 5,5Kw
• Revolutions : 2900 Rpm
• Noise Level : 100 dBA
• Emergency Switch : Included
• Pressure Adjustment : Included
• Blade Protection : Included
• Succion connection : Included
• Smoke Extractor : Included
• Motor Brake : Optional
• Special Voltage : Optional
