Diaphragm valve B935

pneumaticmix-prooffor water

MAIN BENEFIT/USP Complete separation between two different products Maximum hygiene (3A certified) Easy maintenance without the need for special tools Valve bodies made from solid bar Balanced valve members made from solid bar Auxiliary washing system (optional) Upper and lower lift control (optional) Serviceable actuator The B935 is a double seat (mix-proof) valve with an extremely modern and compact design. The valve directs and controls the flow of two different liquids simultaneously, guaranteeing total separation between the two to avoid any risk of contamination. Extremely effective in production plants for health-hygiene applications, this valve means a reduction in the number of single seat valves required and consequently optimizes the use of available installation space. The valve bodies and balanced valve members, made from solid bar to guarantee higher resistance against water hammer, the auxiliary washing system (optional) and the detection of any leaks by means of the separation chamber between the two valve members, makes the B935 one of the safest, most hygienic and reliable valves available. STANDARD FEATURES EPDM, FKM, HNBR and PTFE gaskets
