Digital I O module ANTARES 4TI

4-Iremotesafety

The ANTARES 4TI Remote I/O Module is operated and supplied with power by means of the Rail Control Unit (RCU) ANTARES. This module allows the intrinsically safe connection of 4 Pt100, Pt1000, resistors or potentiometers. The hotswap capability allows the electronic unit to be replaced without disconnecting from voltage even in an explosive atmosphere. The internal and galvanically isolated bus connection is established by simply plugging the modules to the RCU. A bus rail is not necessary. Open circuit/short circuit monitoring can be programmed for each channel. The bus status messages and individual messages per channel are displayed by the LEDs. This also enables diagnostics on the module. The Software ANTARES Designer allows parameters to be set for the sensor type. See the system description for installation instructions. Features 4 channels temperature in Pt100, Pt1000 or restistor up to 10 kOhm 2-, 3-, 4-conductor technology Integrated bus rail Installation in ATEX Zone 1/2 or Zone 21/22 Hot-Swap Galvanic isolation between the inputs and the system Line break/short-circuit monitoring Plug-in and codable spring clamps Marking Ex II 2(1) G Ex ib [ia Ga] IIC T4 Gb Ex II 2(1) GD Ex ib [ia IIC Ga] [ia Ga] [ia IIIC Da] IIB T4 Gb Ex II (1) D [Ex ia Da] IIIC Ex II (1) GD [Ex ia Da] [Ex ia IIC Ga] [Ex ia IIB Ga] IIIC Ex ib [ia Ga] IIC T4 Gb Ex ib [ia IIC Ga] [ia Ga] [ia IIIC Da] IIB T4 Gb [Ex ia Da] IIIC [Ex ia Da] [Ex ia IIC Ga] [Ex ia IIB Ga] IIIC Ambient temperature -20 °C up to +60 °C
