Piston compressor I 22 series

breathing airairelectrically-powered

Tailored to meet the needs of your application Very easy to maintain: Thanks to proven BAUER system components Fully automatic compressor control: B-CONTROL MICRO Little space required: Thanks to compact horizontal design External P 80/P 100 filter system: Providing you with clean breathing air conforming to DIN EN 12021¹, the standard for breathing air The I 22 series by BAUER KOMPRESSOREN is tailor-made to deliver high performance in professional applications under the toughest conditions. Outstanding ease of maintenance is just as much a matter of course for us as the wide range of possible applications - optimally matched to your specific needs. Your IK 22 series compressor block has been designed for the most demanding professional applications. Dimensioned for more than 30,000 operating hours, it has proven its worth in thousands of application scenarios. With their outstanding surface hardness, plasma-nitrided and plateau-honed cylinders are able to achieve extremely long service lives combined with low energy consumption and reliable oil lubrication of cylinder surfaces. Furthermore, wear-resistant piston rings in the final stage minimize running costs. The compressor block is both efficient and reliable. Stainless steel cooling ribs provide the basis for particularly efficient cooling and thus very long service life. The units of the new K 22 series are designed with direct coupling. ¹ If the units are maintained and installed correctly as described in the user manual and subject to the BAUER AERO-GUARD being used if CO2 concentration in the intake air exceeds prescribed standard values.
