Automatic denesting machine TDM 9105

for syringes

Denesting and detraying module for opening tubs and trays and removing vials Tray processing: After loading, the tray is opened manually and then placed in the inversion unit. Once the tray is inverted, it is removed and the vials are transferred manually to the next module. Tub processing: After the RTU tubs are loaded, the foil and liner are removed. The next processing step depends on what downstream module is used. After opening, the tub is either transferred to the module downstream by a conveyor, or the nest is removed from the tub with a handling tool and positioned for automatic denesting of the containers. • Tray width: max. 310 mm • Tray length: max. 400 mm • Tray height: max. 80 mm • Nested containers: 0.5 - 50 ml
