LED stroboscope MINISTROB 2600 LED

portabledigital

The pocket-size stroboscope model MINISTROB 2600 LED is used for rational and vibrating speed measurements as well as for the observation of fast moving periodic or quasi-periodic mechanisms mainly for industrial application. Special features: small dimensions, ultra-light weight, trouble-free, processor-technologie, precise fine adjustment of flash frequency by foil key pad with cursor setting, standby with data-hold function, restart with last measured value by tipping any arrow key, automatic power "OFF" with last measured value stored, stabilized voltage, temperatur constant. General Data: Light Source: 20 white light LED´s of high luminous intensity Flash duration: approx. 40 - 180µs Frequency range: 1 - 335 Hz = 60 - 20100 RPM (min-1) with automatic flash power control Trigger action: internal oscillator - Internal control: adjustable via foil pad with cursor function, standby (after 2minutes) with data-hold function, automatic switch-off with storage function of the last set value.
