Inductive proximity sensor DC80/5800A
electromagneticrectangularNAMUR

Inductive proximity sensor - DC80/5800A - BDC ELECTRONIC S.r.l. - electromagnetic / rectangular / NAMUR
Inductive proximity sensor - DC80/5800A - BDC ELECTRONIC S.r.l. - electromagnetic / rectangular / NAMUR
Add to favorites
Compare this product


Characteristics

Technology
inductive, electromagnetic
Shape
rectangular
Output signal
NAMUR
Supply voltage
8VDC, 9VDC
Material
plastic
Protection level
explosion-proof, ATEX, EMC, IP67
Other characteristics
safety
Measuring range

40 mm
(1.57 in)

Process temperature

Min.: -20 °C
(-4 °F)

Max.: 60 °C
(140 °F)

Description

NAMUR SERIES - diameter 80 mm • ATEX certified II 1GD for zone 0;20 • Cable and connector output • General features: Suitable for detection of large targets. The special material of the housing allows the use without additional protections against electrostatic charges. Technical data: • Supply voltage according NAMUR: 7,7 ÷ 9 Vdc • Max ripple: 10% • Consumption at 8,2 V with Rx = 1000 Ω with metal: ≤ 1 mA without metal: ≥ 3 mA • Temperature range: - 20° ÷ + 60°C • Max thermal drift of sensing distance Sr : ± 10% • Repeat accuracy (R): 2% • Cable conductor cross section: 0,75 mm2 • Marking: II 1D Ex iaD 20 T80° C II 1G Ex ia IIC T6 • Certified IMQ 08 ATEX 010 • Electromagnetic compatibility (EMC) according to EN60947-5-2 • According to: EN60947-5-6/EN60079-0/EN60079-11/EN60079-26 • Shock and vibration resistance according to EN60068-2-27/EN60068-2-6 Safety parameters: • Vi max: 13,5 V • Ii max: 60 mA • Ci max: 100 nF • Li max: 100 μH • Pi max: 200 mW These sensors must be used in conjunction with associated apparatus (See Sect. E) Use in hazardous area according to instruction manuals
