Automatic dispenser AMP8805-1000-0000

modularservo-controlledmodular

Via the AMP8805 distribution module, the AMP8000 system can be cascaded using just one short cable in such a way that even complex machines and lines can be implemented in simple topologies. Up to five outputs are available to connect further distributed Servo Drives or distribution modules. Because of their high protection rating, the AMP8805 distribution modules can be directly integrated into the machine layout. This reduces the overall cable lengths and wiring effort considerably, because only a single cable needs to be routed from the control cabinet to the machine. To store energy efficiently, the coupling modules are equipped with capacitors. Additional EtherCAT P Box modules can be installed easily and quickly via the integrated EtherCAT P output in order to integrate further I/Os or data acquisition applications. Function - distribution module Channels - 5 EtherCAT P outputs - 1 x M8 DC-Link voltage - 430…848 V DC DC-Link output current - ∑ max. 20 A DC System bus - EtherCAT Drive profile - CiA402 according to IEC 61800-7-201 (CoE) Ambient temperature (operation) - 0…+40 °C Approvals/markings - CE, cULus, EAC
