Frame Style - -
4-Post -
Special Features - -
• Fully encapsulated rubber pad box
• 16”-diameter forming area -
Intended Use - -
Used to form miscellaneous sheet metal parts for the aerospace industry
Custom Features:
16-inch forming chamber; ideal for low-volume, high-mix production
Fully encapsulated rubber pad box traps the rubber during forming, preventing it from extruding outside of the work area
Rubber pads act as top tool, eliminating need for mated dies
Easily moved with fork lift slots in the base
Kidney loop filter/cooler circuit with thermostatically controlled fan motor
Low level float switch and high temperature shut down switch
Calculated Ram Speeds: Approach 38 IPM; Pressing 10 IPM; Return 55 IPM
Light curtains guarding the front and rear openings of the press
(4) chrome housing posts with graphite impregnated bronze bushings for superior ram guidance and rigidity
Common Features on Beckwood Presses:
Heavy duty box beam design for superior rigidity and modular tie rod assembly utilizing pre-tensioning nuts for optimum performance
Fully adjustable Parker cylinders with full rated tonnage throughout the stroke
PressLink Remote Support module for complementary diagnostics & troubleshooting
Dual linear and pressure transducers in the main ram cylinders for optimal reliability and redundancy
Allen Bradley or Siemens PLC, programmable control system with touch screen HMI and Recipe Functionality
Structure designed for Infinite Life in accordance with rigorous simulation analysis through FEA (Finite Element Analysis) design testing
Backed by Beckwood’s industry leading dedicated service and support team
