1 × Ethernet, 4 × serial, 1 × USB as standard
Operating temperature -10° to +50° C
CE, FCC, UL approvals
General description
Life cycle status - Active
Warranty - 2 year
Certifications
General - CE, FCC, UL 61010-2-201
Safety - UL 61010-1, UL 61010-2-201, CAN/CSA-C22.2 No. 61010-1, CAN/CSA-C22.2 No. 61010-2-201
Mechanical
Mechanical size - 202 x 152 x 37mm
Number of touches - 1million finger touch operations
Cut-out size - 186 x 136mm
Weight - 0.58 kg
Housing material - Plastic (PC+ABS), Gray
Buzzer - No
LED - No
Power
Input voltage - 24 V DC (18 to 32 VDC) CE: The power supply has to be conform with the requirements according to IEC 60950 and IEC 61558-2-4.UL and cUL: The power supply has to be conform with the requirements for class II power supplies.
Power consumption (max) - 5.6 W
Input fuse - Internal DC fuse
System
CPU - ARM Cortex A8 600MHz
RAM - 512 MB
FLASH - 2 GB
Display
Backlight life time - 20000 hours
Backlight brightness - 400 cd/m²
Backlight dimming - Industrial Dimming
Digtal IO
Digital output - No
Serial communication
Number of serial ports - 1port9pinDsub, 1port3pinScrew
Ethernet communication
Number of Ethernet ports - 1
Expansion interface
Expansion port - No
SD card - No
USB - 1
Environmental
Operating temperature - -10°C to +50°C
Storage temperature - -20°C to +60°C
Shock - 15g, half-sine, 11ms according to IEC60068-2-27
Vibration - 1g, according to IEC 60068-2-6, Test Fc
Sealing back - IP20
Humidity - 5% – 85% non-condensed
