1.5 GB application memory
Ethernet 2x100 Mbit
CODESYS control integrated
CE, FCC, KCC, UL approvals
DNV GL, KR, LR, ABS, CCS, RS marine approvals
General description
Life cycle status - Active
Warranty - 2 year
Certifications
General - CE, FCC, KCC, UL 61010-2-201
Marine - KR, LR, ABS, CCS, NK, DNV GL, RS
Safety - UL 61010-1, UL 61010-2-201, CAN/CSA-C22.2 No. 61010-1, CAN/CSA-C22.2 No. 61010-2-201
Mechanical
Mechanical size - 410 x 286 x 61mm
Number of touches - 1million finger touch operations
Cut-out size - 394 x 270mm
Weight - 3.85 kg
Housing material - Powder-coated aluminum, Black
Power
Input voltage - 24 V DC (18 to 32 VDC)CE: The power supply must conformwith the requirements according to IEC 60950 and IEC 61558-2-4.UL and cUL: The power supplymust conformwith the requirements for class II power supplies.
Power consumption (max) - 33.6W
Input fuse - Internal DC fuse
System
RAM - 2 GB
FLASH - 2GB SSD(eMMC), 1.5GB free for application
Display
Backlight life time - 30000 hours
Backlight brightness - 1000 cd/m2
Backlight dimming - Marine optimized dimming
Softcontrol
Codesys runtime version - 3.5
Codesys EtherCAT - Yes
Codesys Modbus Ethernet - Yes
Codesys Modbus RTU - Yes
CANopen - Yes
Non volatile variables - 64 KB
Digtal IO
Digital output - 2xDO Solid state relay, 0.5A@24VDC
Serial communication
Number of serial ports - 1 Port 9pin DSUB
Ethernet communication
Number of Ethernet ports - 2
Communication CAN
Number of CAN ports - 2
CAN port 1 - 0.5 MBit
CAN port 2 - 0.5 MBit
Expansion interface
Expansion port - Yes, ciX expansion module
SD card - SD and SDHC
Environmental
Operating temperature - -10°C to +60°C
Storage temperature - -20°C to +70°C
