Compression testing machine YAW-5000F

computer-controlledfor cementconcrete

YAW-5000F Computer Controlled Servo Hydraulic Compression Testing Machine is consisted of load frame, oil source, control cabinet, computer etc. It adopts hydraulic load, oil pressure transducer to measure load. Computer control the test process. PC screen display the test data and curve, with data analysis, storage and print function. Standards In accordance with or exceed the requirements of the GB/16826-2008. Applications It is mainly used to various materials compression test such as cement, concrete, brick of diverse materials, rubber tray, concrete component, metal component anti-compress strength. • Max. capacity (KN) : 5000 • Measuring range : 2%-100% of FS • Relative error of reading : ≤±1% • Compression space (mm) : 1500 • Compression platen size (mm) : 700*800 • Max. piston stroke (mm) : 150 • Max. piston speed (mm/min) : 50 • Measuring range of displacement (mm) : 0-150 • Up and down speed of crosshead (mm/min) : 170 • Loading measurement device : Oil transducer • Column clearance (mm) : 1000 x 800 • Oil pump motor power (KW) : 7.5 • Moving motor power(KW) : 3 • Load frame dimensions (mm) : 1255 x 1145 x 3900 • Cabinet dimensions (mm) : 1100 x 700 x 930 • Oil source dimension(mm) : 1200 x 850 x 1150 • Load frame weight (KG) : 12000 • Control cabinet weight (KG) : 300 • Oil source weight(KG) : 1200
