Ball valve DQ41/7 Fwith handwheelpneumaticelectric
Add to favorites
Compare this product
Characteristics
- Type
- ball
- Operation
- with handwheel, pneumatic, electric
- Function
- for control
- Applications
- cryogenic
- Other characteristics
- anti-static, fire-safe, for nitrogen
- DN
Min.: 15 mm
(0.591 in)Max.: 600 mm
(23.622 in)- Temperature
Min.: -196 °C
(-321 °F)Max.: 121 °C
(250 °F)
Description
Cryogenic ball valve
Product type
On/Off type
Valve Type -
Cryogenic ball valve
Model
DQ41/7 F
Size
NPS 1/2～NPS 24
Design temp.
-196℃～121℃
Design pressure
CLASS 150～CLASS 2500
Material
CF8,F304,CF8M,F316
standard
API 6D,ISO 17292,API 608,BS 5351,BS 6364
Face to face
ASME B16.10
Connection
ASME B16.5,ASME B16.25
Test std.
BS6364,API 598
Operation
handwheel ,worm wheel , electric ,pneumatic
Application
LNG,liquid nitrogen
Other remark 1
Valve stem anti-fow out structure design prevent accident caused by abnormal pressurization of the pipeline.
Other remark 2
Fire-Safe and anti-static design
Other remark 3
extension stem design, stem packing is more reliable
