Disc check valve B6 40

stainless steelspringanti-corrosion

Iprocheck axial check valve The choice of robust and anti-corrosion materials together with the design of the IPROCHECK ensure a long-lasting and maintenance-free product. Flanged type: DN40 up to 250 Working pressure: 16 bar Test pressure: 24 bar Flanges drilling according to standard EN 1092-2 and ISO 7005-2: ISO PN10 and 16 up to DN150 included, ISO PN10 or ISO PN16 for DN200 and DN250 Medium Temperature -10 up to +80°C Sealing: class A according to standard ISO 5208. Tightness weir: from minimum differential pressure of 3 mWC CHARACTERISTICS Anticipated closing thanks to the spring action minimize the intensity of the check valve shock. Hydraulically profiled disc to optimize the passing of the flow and ensure a low head loss. Sealing, even with low pressure – Provided by a flat gasket incorporated into the disc. Stainless steel strainer – Connected to the axial check valve for Foot version. Practical cable-pass for pump cable. Different installations – horizontal flow or vertical flow upwards.
