Fuel transportation truck

3-axlefor construction

ENGINE Manufacturer Mercedes Benz Model OM924LA Configuration Inline 4, turbocharged and intercooled. Gross Power 160 kW (214 hp) @ 2 200 rpm Net Power 152 kW (204 hp) @ 2 200 rpm Gross Torque 810 Nm (597 lbft) @ 1 200 -1 600 rpm Displacement 4,80 litres (293 cu.in) Auxiliary Brake Exhaust Valve Brake Engine Valve Brake Fuel Tank Capacity 200 litres (53 US gal) Certification OM924LA meets Euro III emissions regulations TRANSMISSION Manufacturer Allison Model Standard Non Retarder: 3000P ORS Optional Retarder: 3000PR ORS Configuration Fully automatic planetary transmission with integral retarder. Layout Engine mounted Gear layout Constant meshing planetary gears, clutch operated Gears 6 Forward, 1 Reverse Clutch Type Hydraulically operated multidisc Control Type Electronic Torque Control Hydrodynamic with lock-up in all gears TRANSFER CASE Manufacturer Kessler Series W1400 Layout Remote mounted Gear Layout Three in-line helical gears Output Differential Interaxle 33/67 proportional differential. Automatic inter-axle differential lock. AXLES Manufacturer Bell Model 15T Differential High input limited slip differential with spiral bevel gears. Final Drive Outboard heavy duty planetary on all axles
