Polyamide cable gland JCR02
nitrile butadiene rubber (NBR)stainless steelIP68

Polyamide cable gland - JCR02 - Berardi Bullonerie srl - nitrile butadiene rubber (NBR) / stainless steel / IP68
Polyamide cable gland - JCR02 - Berardi Bullonerie srl - nitrile butadiene rubber (NBR) / stainless steel / IP68
Polyamide cable gland - JCR02 - Berardi Bullonerie srl - nitrile butadiene rubber (NBR) / stainless steel / IP68 - image - 2
Add to favorites
Compare this product


Characteristics

Material
polyamide, nitrile butadiene rubber (NBR), stainless steel
Protection level
IP68, IP69K, self-extinguishing
Other characteristics
metric
Cable diameter

0 mm
(0 in)

Operating temperature

Min.: -20 °C
(-4 °F)

Max.: 100 °C
(212 °F)

Description

Perfect cable gland, metric thread stainless steel • Material Body: AISI303 (Stainless steel) Insert: PA6 (Polyamide) Sealing ring: CR/NBR (Nitrile chloroprene) O-ring: NBR (Nitrile rubber) • Protection grade: IP68 - 5 bar IP69K (tested for M12 - M25 - M50 - M63) • Self-Extinguishing: UL 94 V-2 • Operating temperature: -20°C ÷ 100°C • UL/CSA-FILE: E140310 • Standard test: UL 514B
