Temperature calibrator EJB 9971for thermocouplesprocesscompact
Add to favorites
Compare this product
Characteristics
- Physical quantity
- temperature
- Applications
- for thermocouples
- Options
- process, compact
- Temperature
Max.: 50 °C
(122 °F)Min.: 0 °C
(32 °F)- Voltage
Max.: 100 mV
Min.: -10 mV
Description
EJB 9971 MULTIFUNCTIONAL THERMOCOUPLE PROCESS CALIBRATOR
The EJB 9971 Thermocouple Calibrator measures or simulate 8 types thermocouples (J,K,T,E,R,S,B,N) or millivolt. High accuracy 0,3°C and 0,025% for mV delivers outstanding performance, durability and reliability.
With a push button EJB 9971 is easy to use. It is EMI tolerant, dust and splash resistant, and features a removable battery door for quick battery changes. It is compact, lightweight, and easy to carry.
Display : large (64 x 42 mm) 5 digit LCD
Thermocouple type : J,K,T,E,R,S,B,N
Temperature resolution y : 0,1°C
Temperature error : 0,3°C + 10uV
Range : -10 mV...100 mV
Voltage resolution : 0,01 mV
Voltage accuracy : ± 0,025% + 2 counts
External power option
Fuse : F 0.125A/250V
Dimensions : 205 x 98 x 46 mm
Weight 470 g (incl. battery)
