Hydraulic press HWP 30straighteningassemblyautomatic
Add to favorites
Compare this product
Characteristics
- Operation
- hydraulic
- Function
- straightening, assembly
- Control
- automatic
- Other characteristics
- shop
- Applications
- for sheet metal, repair
- Force
30 tf
- Stroke
380 mm
(14.961 in)- Table width
325 mm
(13 in)- Max. pressure
221 bar
(3,205 psi)- Working speed
3.6 mm/s
- Return speed
18.1 mm/s
- Hydraulic pump power
1.5 kW
- Weight
395 kg
(871 lb)- Overall length
805 mm
(32 in)- Overall width
1,315 mm
(52 in)- Overall height
2,120 mm
(83 in)
Description
Ideal for assembly and straightening work, but also ideal for setting up tools, during load tests and for workpiece checks
Table height adjustment by means of chain and working cylinder
Piston feed either trough hand lever or sensitive hydraulic pump
Fast forward and return speeds for efficient work
Powerful workshop presses for craft and repair shops
Piston can be stopped in any position
Technical specifications
Passage between stand
750 mm
Piston diameter
55 mm
Max. working height
950 mm
Forward speed
9,8 mm/sec.
Standard accessories
Pressure gauge
Height adjustable work table
Overload valve
