Vegetable washing machine HWM-120-4000

drum

Upmatic washing machines TYPE HWM-120-4000 It could hardly be cleaner! The powerful wash with particularly gentle "delta ram profiles" in the drum cleans the product thoroughly and without damage. Thanks to the hydraulic lifting, the wash can be emptied in a very short time. The accumulated impurities can be safely discharged through the steep funnels Technical data: Washing capacity: up to 30 t/h Rated voltage: 230 / 400 V at 50 / 60 Hz Power consumption 5.2 kW Initial filling 5 m³ Fresh water requirement 100-150 l per t/h (depending on degree of pollution) Length 4,400 mm Width 2,200 mm Height 4,000 mm Weight of the machine 3600 kg Connection data HWM 120-3000: Drum drive 1.5 kW Frischwasserbedarf 1,5 m³ Fresh water requirement 1.5 m³ Cheque pump 2.2 kW Length 3,450 mm Width 1,600 mm Height 3,070 mm Weight of the machine 1,900 kg Accessories: OnTop cleaning function with fresh water supply Bar slide Slip monitor (washing drum rotation control) Sludge organs: Hose pinch valve pneum. Knife-gate valve Eccentric screw pump
