For the semi-automatic filling of bagged powders and granules. From 1 kg to 50 kg.
• High precision weighing of all types of powders
• Chopper blades for products that are difficult to dose
• Pouyes ring for the extraction of fine dust
• Easy to clean and disassemble
• Filling cycles recorded for each bag
• In-line integration
The Filler and Doser has been designed to meet the requirements of industrials in the food industry, pharmaceuticals or chemicals.
• Pulverulent products with good or poor fluidity (lump formation, poor flowability)
• Frame with integrated bag support table made of 304 stainless steel
• 60 L hopper made of electropolished 316 stainless steel
• Fluidizing and de-bridging blades made of 316 stainless steel
• PTFE dosing shutter
• Level sensor with hopper full indicator
• Pouyes ring to trap fine dust
• Donaldson vent for air extraction
• Clamp to hold and seal the top of the bag
• Continuous monitoring of dosing speed by means of a brushless motor
• Precia Molen scales: 10g divisions for 30 kg maximum range or 20g divisions for 60 kg maximum range
• Control panel on articulated arm
• Touch screen for managing the dosing parameters
• Start dosing cycle pedal
• Hopper up and down movements by electrically operated jacks positioned at an ergonomic height for easy cleaning
• Power supply: 400 V three-phase + earth
• Power rating: 4 KW
• Frequency: 50 Hz
• Air supply: compressed air at 6 bars
