• Variable blade speed controlled by inverter
• Main drive: Gearbox
Capacity (inch / mm): - 20° 9"/ 230mm 12.2" x 9" / 310mm x 230mm - 45° 8.26"/ 210mm 8.26" x 8.26"/210mm x 210mm - 60° 5.51"/140mm 5.51" x 3.93" / 140mm x 100mm
Bi-direction angle cutting: - +45°~-60°
Blade speed (inch/sec,m/min): - 23.62 - 45.93 (inch/sec) / 36-70 (m/min)
Blade size (inch/mm): - 1.06" x 0.035" x 114.56" / 27mm x 0.9mm x 29710mm
Vice clamping type: - Manual
Blade drive motor (KW): - 1.8KW/1.3KW
Hyd. pump motor (KW): - 0.42KW
Main drive: - Wormbox
Machine Size (L x W x H) (inch/mm): - 63" x 31.49" x 59.05" (1600mm x 800mm x 1500mm)
