Spray nozzle N seriesfor liquidsfull-conealuminum
Add to favorites
Compare this product
Characteristics
- Function
- spray
- Fluid
- for liquids
- Stream
- full-cone
- Material
- stainless steel, brass, aluminum, bronze, titanium
- Applications
- for the food industry, for the steel industry, for the chemical industry, fire protection, refueling, for petrochemical applications, for the mining industry, for water treatment
- Spray angle
- 90°, 120°, 110°, 100°
- Other characteristics
- compact, male, spiral
- Orifice diameter
Max.: 1.29 in
Min.: 0.19 in
- Flow
Max.: 597 us gal/min
(2,259.89 l/min)Min.: 3 us gal/min
(11.36 l/min)- Pressure
50 psi, 150 psi
Description
Designed specifically with critical fire and explosion suppression applications in mind
One-piece, no internal parts
Clog-resistant
Optional protective cover
All N1-N3W nozzles provided with integral strainer
N1-N3W strainer: 316 SS, 24 mesh (0.027" opening)
Factory Mutual, U.S. Coast Guard, and Lloyd's Register approved models
HOW SPRAY PATTERN IS ACHIEVED
The spray pattern of the spiral nozzle is formed by the fluid shearing along with the turns of the spiral, which produce multiple concentric cones. These cones form 2 to 3 bands of relatively coarse droplets, surrounded by wider bands of relatively fine droplets.
The large surface area of spray improves evaporation and cooling.
