Square tube connector 1204
roundsteelpolyamide

square tube connector
square tube connector
square tube connector
Add to favorites
Compare this product


Characteristics

Structure
round, square
Material
polyamide, steel
Diameter

Max.: 12.1 mm
(0.476 in)

Min.: 10.1 mm
(0.398 in)

Description

Use: reflector with clip pin, the tightening torque is not constant over time. State of supply reinforced polyamide connector, 1 UNI 5931 socket head screw and 1 UNI 5588 hexagon nut in galvanised steel. Tightening torque 4.9 Nm (M5). Warnings: if combined with commercial 12ø round tubes, check that the tolerance corresponds to that of our Part 2012; if combined with 10☐ square rods available on the market, check that the tolerance corresponds to that of our Part 1789.
