Electrical power supply connector 09 3105 00 03DINmalescrew
Add to favorites
Compare this product
Characteristics
- Type
- electrical power supply
- Format
- DIN
- Connection type
- male, screw, locking
- Size
- M5
- Electrical characteristics
- current, voltage
- Product applications
- panel
- Protection class
- IP67
- Other characteristics
- immersion
- Primary current
1 A
- Voltage
60 V
- Operating temperature
Max.: 80 °C
(176 °F)Min.: -25 °C
(-13 °F)
Description
This male panel mount connector with screw locking and a pin count of 3 is according to its protection class IP67 Dust-tight and has complete protection against contact and protection against temporary immersion. It can be used in areas with a pollution degree of 3. In places where contamination can occur that is conductive or can become conductive through condensation. With temperatures ranges of -25 °C/80 °C is this unshielded M5 male panel mount connector designed for both severe cold and severe heat. Due to the qualified rated voltage of 60 V and the rated current of 1,0 A it is perfectly tuned for its field of application. It complies with the type standard DIN EN 61076-2-105.
