Radar level sensor CNCR-220
for liquids4-20 mAfor storage tanks

radar level sensor
radar level sensor
radar level sensor
radar level sensor
radar level sensor
radar level sensor
radar level sensor
Add to favorites
Compare this product


Characteristics

Technology
radar
Medium
for liquids
Interface
4-20 mA
Applications
for storage tanks, rugged, river
Other characteristics
compact, IP67, IP66
Level range

7 m, 15 m
(22'11" , 49'02" )

Process pressure

Max.: 3 bar
(43.51 psi)

Min.: -1 bar
(-14.5 psi)

Process temperature

Max.: 80 °C
(176 °F)

Min.: -40 °C
(-40 °F)

Description

The CNCR-220 is a compact 80 GHz non-contact radar for distances up to 49 ft (15 M). It installs using a 1.5” threaded NPT or 1.5” threaded straight NPT connection. The enclosure is rated IP66/IP67, Type 4X to protect from dust and water damage. CNCR-200 Non-Contact Radars: 80 GHz accuracy and 1.5” NPT mounting Bluetooth setup on your phone. Mounts fast through existing threaded or straight NPT connections. Measures liquid tanks, plastic IBCs through the wall, or short solids silos. Looking for an alternative to an ultrasonic sensor? Continuous level measurement with the 80 GHz radar signal is focused in a narrow beam that measures with accuracy of +/- 0.2”. Want a radar sensor that works under harsh conditions? Sensor is immune to condensation, turbulence, and foam. Not affected by fluctuating temperatures or pressure. Models to make the most of your measurements: CNCR-210: measures up to 26 feet CNCR-220: measures up to 49 feet CNCR-230: Up to 49 feet plus an LED display Note: For solids, distances are 50% less. Need hazardous approvals? Check with the factory. You and your maintenance crew will love these sensors: No dead zone, measures to sensor face Two-wire 4-20 mA output IP66/IP67, Type 4X dust and moisture resistant PVDF enclosure FKM seal material for longevity under harsh conditions Try this level sensor in these applications and more: Foods, fats, and oils for humans or animals Municipal drinking or purified water plants Industrial processing of chemicals or fluids Day tanks, cooling towers, or waste sumps Plasticizer or resin tanks or silos Oil and fuel storage tanks Flood, river, dam, or sewer levels
