Rotary blade cutting system ACC 550 HS

for paper and cardboardstackingmulti-function

For automated collating and stacking for complete deck of cards with a stack height of up to 40 mm. • Fast make-ready in under 1/2 hour • High productivity rate; up to 2000 decks per hour • Automated process, reduces labor to a single person • Incomplete decks are rejected using optical card control • Deck formation from one or two printed sheets • Processing of square or round cards • Capable of integrating in-line with other downstream systems • Infeed: Shingle belt • Sheet format max.: 550 x 750 mm (21.6" x 29.5") • Sheet format min.: 210 x 297 mm (8.2" x 11.7") • Card format max.: 105 x 148 mm (4.13" x 5.82") • Card format min.: 42 x 57 mm (1.65" x 2.24") • Stack height max.: 40 mm (1.57") • Production rate: up to 2'000 decks/h • Mobility: mobile on wheels • Space requirement: approx. 2’200 x 1’550 mm (L x W) • Weight: approx. 400 kg • Power supply: 3 x 400VAC / N / PE 50/60Hz / 16A (Standard) • Control: 24 VDC • Capacity of drives: 2,0 kW
